Red Lion Controls NT24K-16M12 16-Port Gigabit Managed IP67 rated Industrial Ethernet Switch (16 10/100/1000BaseTX Copper M12 X-Code Ports)
MODEL NT24K-16M12
Contact supplier for technical support on: 877-432-9908
$4,383.00 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Free Gift with this product
Typically Ships in: 1 day
Returnable: See conditions
16 10/100/1000BaseTX Copper M12 X-Code Ports
-40°C to 85°C Operating temperature
>2M hours MTBF
IP67 Rated enclosure
Dustproof
Protection against low/high pressure water jets
Safe for temporary immersion in water
10-49 VDC redundant power inputs
ESD and surge protection on all ports
Auto Sensing 10/100/1000BaseTX, Duplex, and MDIX
Store-and-forward Technology
16k MAC Addresses
USB Configuration Port
Full wire speed communications
Auto sensing speed and flow control
Backup and restore via recovery card or XML configuration file
Fully Managed Features:
Jumbo Frame Support
SNMP v1, v2, v3
SSH/SSL/HTTPS
Web Browser Management
Detailed Ring Map and Fault Location Charting
802.1d, 802.1w, 802.1D RSTP
Port Trunking and Mirroring
802.1Q tag VLAN and Port VLAN
802.1x with RADIUS Remote Server Authentication
802.1p QoS, Port QoS and DSCP
Event Log/Syslog
SNTP (Simple Network Time Protocol)
Multi-Member N-Ring™ Technology with ~30ms Healing
N-Link™ Redundant Ring Technology
N-View™ Monitoring and Firmware Management Technology
EtherNet/IP™ CIP™ Messaging
802.1AB-2005 LLDP (Link Layer Discovery Protocol)
Web configuration
IGMP Auto Configuration
SKU: 286716
